Sumer Adela Steam Sterilizers / Autoclaves
CSSD Steam Sterilizers / Autoclaves (100-1200 L Capacity)
General Specifications
Control system based on micro-computer technology, ensuring safe operation
The computerized control unit assuring a fully automatic operation throughout the entire
cycle
All sterilization phases are displayed and controlled on LCD touch screen display
Chamber, steam jacket, door and steam generator that are made of 316 L stainless steel
Single/Double Sliding Door or Single/Double Flywheel Door
Production between 100-1200 L volume on demand
Generator power: varies according to device capacity
Working pressure: 3.5 bar, test pressure: 7.2 bar
Pressure measurement: -1.0/+5.0 bar
Temperature measurement: 100 °C-140 °C (± 1 °C)
Silicon seal ensuring impermeability against acid and chemical substances
Manuel system for emergency situations
Automatic open-close for sliding door systems
Pneumatic or automatic electro motor controlled sliding doors having required features
Door safety lock and Door closing safety
Special safety valve (CE) in chamber and jacket, PT 100 heat sensor, pneumatic valves in
the steam lines
4 pieces of calibrated manometers for single door models and 8 pieces for double door
models vessel, jacket, generator and seal
HEPA filter filtering particles larger than 0.3 micron (%99.99)
Water saving system, standby mode, fast heating mode
Preset program and user-defined custom program memory (121 °C – 134 °C)
Test programs: Bowie&Dick and vacuum leakage.
Bypass system
High capacity, quiet running vacuum pump with water ring
PLC (Microprocessor) control system with color touch screen – touch screen for clean side
in double door models
RS232 I RS485 output, optional
Independent record system from automatic control system
Visual, written and audio alarm system indicating the status of fault on the display
Sumer is a leading manufacturer of autoclave, washer-disinfectors, operating table, blood refrigerators/ freezers, mother milk refrigerators/freezers, warming cabinets and stainless steel hospital equipments with more than 39 years of experience. The production facilities are 25,000 m2 located in Baskent OSB, Ankara and all of products are SFDA, ISO 9001, ISO 9001/14001, ISO 13485, HYGCEN(Germany/Austria), CE (97/23/CE,93/42/CE) and TSE EN 285 certified for laboratory applications. Our products are internationally recognized for an elegant and user-friendly design, "Sumer" reliability based upon 39 years of experience in manufacture, benchmark performance and energy-saving features. For More information please visit our website at: www.sumerinc.com and contact us at [email protected].
